Font Liquid Cooling Kit
Your most economical, lowest foot print and easiest way to cool your font and taps for a perfect first pour every time. Enjoy your preferred drinks from your now refreshed font!
Turn your existing font into a liquid cooled font with this economic kit. No more first pour foam, save beer with this one simple kit!
Our Liquid Font Cooling Kit has been designed to use the cold generated by your KegMaster to turn your font into a liquid cooled font. All you have to do, is install the flood font disc, replace your font fan and start cooling your font like a professional.
Please ensure that your font is floodable first. If your font isn't outright floodable, you might be able to DIY seal it and turn it into a floodable font. Please also note that this kit is not designed to ice up the font, this kit is designed to cool your font more effectively than the pre-installed air-cooling kit.
Parts included:
1x Flooded font disk with in/out let and up to 4 beer lines
2x Plugs for unused disc holes
1x disk sealing o-ring
1x insert tube
1x fan with heat exchanger
1x power pack
Not included:
1x connector to connect the line to the steel tube
Instructions for Premium KegMasters:
Unplug your KegMaster kegerator from the wall
Detach your KegMaster fan connection inside your fridge, then unscrew it from the top and remove it entirely
Install the new fan with built in heat exchanger in place of your previous fan and connect it via the connector
Next, you will need to install the flooded disc on top of your KegMaster:
- unscrew the 4 font screws
- remove the font and pull the lines out entirely. At this stage you will need to remove the disconnects from your lines and pass the lines through the disc holes then reattach the disconnects
- set the font disc in place, ensure the seal is seated properly (seal facing upwards to seal between the disc and the font) then set the font back on top of your KegMaster and screw the 4 font screws back on
Attach your preffered fitting on one end of the steel tube where you will attach your cooling line, then gently push the other end of the steel tube through the middle hole of the flooded disc all the way to the top of your font
Connect your cooling line to the steel tube; this will be the liquid out line
Connect your second cooling line to the barb fitting of the flooded disc; this will be your liquid in line
Connect the liquid 'in' line to the pump 'out' side
Connect the pump 'in' to the heat exchanger
Connect the liquid line 'out' to the heat exchanger
